Order code not found. You may mean this product:
090-3

Pin Header SMD 2,54 mm 090 3

Pin headers, Pin Header SMD 2,54 mm

Double row

Available variations
Compare product
Illustration Pin Header SMD 2,54 mm 090 3
Technical data
Moreless
Pitch (mm) 2,54
Pincount 4, 6, 8, 10 ... 80
Polarising no
Locking No
Material contact Copper alloy
Plating contact Au, Sn
Material insulator High temp. thermoplast UL94V-0
Rated current IEC 3,0 A
Rated voltage 250 V RMS / V DC
Withstand voltage 500 V RMS for 1 Minute
Operating temperature -40°C to +105°C
Max. processing temper. 260°C for 10 seconds
Board termination SMD Gull Wing SMD Gull Wing
Orientation to PCB Vertical Vertical
No of rows 2
Cap With cap, Without cap
Packaging Reel, Tube
A (Length) 10,40, 12,50, 14,20, 15,50 ... 9,10
Pin Header SMD 2,54 mm 090 3 Pin Header SMD 2,54 mm 090 3
A (Length)B (Mating)
9,105,30
10,406,60
12,508,70
14,2010,40
15,5011,70
17,6013,80
Configurate Your Product
Order code
090-3-???-0-?-X??-????
Please finish Product configuration first

Pincount
Plating contact
Packaging
Cap
A (Length)
