Order code not found. You may mean this product:
090-1

Pin Header SMD 2,54 mm 090-1

Pin headers, Pin Header SMD 2,54 mm

Available variations
Compare product
Illustration Pin Header SMD 2,54 mm  090-1
Technical data
Moreless
Pitch (mm) 2,54
Pincount 3, 4, 5, 6 ... 40
Polarising no
Locking No
Material contact Copper alloy
Plating contact Au, Sn
Material insulator High temp. thermoplast UL94V-0
Rated current IEC 3,0 A
Rated voltage 250 V RMS / V DC
Withstand voltage 500 V RMS for 1 Minute
Operating temperature -40°C to +105°C
Max. processing temper. 260°C for 10 seconds
Board termination SMD Gull Wing SMD Gull Wing
Orientation to PCB Vertical Vertical
No of rows 1
Cap With cap, Without cap
Packaging Reel, Tube
A 10,40, 12,50, 14,20, 15,50 ... 9,10
 Pin Header SMD 2,54 mm  090-1 Pin Header SMD 2,54 mm  090-1
A B
9,105,30
10,406,60
12,508,70
14,2010,40
15,5011,70
17,6013,80
