Order code not found. You may mean this product:
597-5

D-SUB Right Angled Series 597 Variant 5

DSUB, D-SUB Right Angled

D-SUB right angled version. A wide range of mounting accessories is available. US and european standard.

Available variations
Compare product
Technical data
Moreless
Material insulator High temp. thermoplast UL94V-0
Plating contact Selective Au
Plating shell Ni
Packaging Standard
Board terminationSMD Floating SMD Floating
Material contact Copper alloy
Rated current 1,0 A
Rated voltage 125 V RMS / V DC
Withstand voltage 500 V RMS for 1 Minute
Operating temperature -55°C to +105°C
Max. processing temper. 260°C for 10 seconds
Pincount 9
Orientation to PCBParallel Parallel
No of rows 2
Industry standard DSUB
Mounting option DSUBRivet #4-40 Rivet #4-40
Color black
No of contactsABCDE
930,8025,0016,9216,3016,00
930,8025,0016,9216,3016,00
Please finish Product configuration first
