Order code not found. You may mean this product:
597-3

D-SUB Right Angled Series 597 Variant 3

DSUB, D-SUB Right Angled

D-SUB right angled version. A wide range of mounting accessories is available. US and european standard.

Available variations
Compare product
Technical data
Moreless
Pincount 9, 15, 25, 37
Material contact Copper alloy
Plating contact Au, Selective Au
Material insulator Thermoplast UL94V-0
Rated current 5,0 A
Rated voltage 125 V RMS / V DC
Withstand voltage 500 V RMS for 1 Minute
Operating temperature -55°C to +85°C
Max. processing temper. 230°C for 10 seconds
Board termination Through hole Through hole
Orientation to PCB Parallel Parallel
No of rows 2
Industry standard DSUB
Mounting option DSUB Jack screw inserted, Rivet, Rivet + jack screw 11,80 mm attached, Rivet + jack screw inserted
Color black, blue, white
Plating shell Ni
Packaging Standard
Pincount
009
015
025
037
