D-SUB Right Angled Series 597 Variant 2

DSUB, D-SUB Right Angled

D-SUB right angled version. A wide range of mounting accessories is available. US and european standard.

Available variations
Compare product
Technical data
Material insulator Thermoplast UL94V-0
Plating contact Selective Au
Plating shell Ni
Packaging Standard
Board terminationThrough hole Through hole
Material contact Copper alloy
Rated current 5,0 A
Rated voltage 125 V RMS / V DC
Withstand voltage 500 V RMS for 1 Minute
Operating temperature -55°C to +85°C
Max. processing temper. 230°C for 10 seconds
Pincount 9, 25
Orientation to PCBParallel Parallel
No of rows 2
Industry standard DSUB
Mounting option DSUB No accessories, Rivet, Rivet + jack screw 10,00 mm attached, Rivet + jack screw inserted
Color black, blue
