600-3

D-SUB IP-67 Solder cup 600 3

DSUB, D-SUB IP-67

Solder cup version.

Pincount	9, 15, 25
Gender	Female, Male
Material contact	Copper alloy
Plating contact	Au
Material insulator	Thermoplast UL94V-0
Rated current IEC	5,0 A
Rated voltage	125 V RMS / V DC
Withstand voltage	500 V RMS for 1 Minute
Operating temperature	-55°C to +85°C
Max. processing temper.	230°C for 10 seconds
No of rows	2
Connection type	Solder cup
Industry standard	DSUB
Mounting option DSUB	Rivet #4-40, Rivet + jack screw attached, Rivet + jack screw inserted
Color	black
Plating shell	Ni, Sn
Packaging	Standard

Configurate Your Product

Order code

600-3-????-??0?F-BS0

Please finish Product configuration first

Pincount

Gender

Mounting option DSUB

Plating shell
