Technical data
Moreless| Pincount | 15 |
| Gender | Female |
| Material contact | Copper alloy |
| Plating contact | Selective Au |
| Material insulator | Thermoplast UL94V-0 |
| Rated current IEC | 3,0 A |
| Rated voltage | 60 V RMS / V DC |
| Withstand voltage | 500 V RMS for 1 Minute |
| Operating temperature | -55°C to +85°C |
| Max. processing temper. | 230°C for 10 seconds |
| Board termination |
Through hole
|
| Orientation to PCB |
Parallel
|
| No of rows | 3 |
| Industry standard | DSUB |
| Mounting option DSUB | Rivet, Rivet + jack screw 10,00 mm attached, Rivet + jack screw inserted |
| Color | black, blue, white |
| Plating shell | Ni |
| Packaging | Standard |
Drawing / Dimensions
Moreless
| Polzahl | A | B | C | D | E | F |
|---|---|---|---|---|---|---|
| 15 | 30,81 | 24,99 | 16,92 | 16,33 | 2,29 | 0,14 |
