Technical data
MorelessPitch (mm) | 1,27 |
Mating pin size (range) | ø 0,38-0,50 |
Pincount | 9, 12, 15, 18 ... 150 |
Gender | Female |
Polarising | no |
Locking | No |
Material contact | Copper alloy |
Plating contact | Sn |
Material insulator | High temp. thermoplast UL94V-0 |
Rated current IEC | 1,0 A |
Rated voltage | 100 V RMS / V DC |
Withstand voltage | 500 V RMS / V DC |
Operating temperature | -40°C to +105°C |
Max. processing temper. | 260°C for 10 seconds |
Board termination | Through hole |
Orientation to PCB | Parallel |
No of rows | 3 |
Clip style | 3 finger clip |
Plating clip | Au, Au 0,75 µ |
Row distance (mm) | 1,27 |
Material clip | Berylium Copper |
Contact style | Turned |
Socket layout | Three-row |
Packaging | Standard |
