Technical data
Moreless| Pitch (mm) | 5,08 |
| Pincount | 2, 3, 4, 5 ... 24 |
| Material contact | Copper alloy |
| Plating contact | Sn |
| Material insulator | PA 6.6, UL94V-0 |
| Rated current IEC | 16,0 A |
| Rated voltage | 300 V AC |
| Withstand voltage | 2500 V AC for 1 Minute |
| Operating temperature | -40°C to +105°C |
| Board termination |
Through hole
|
| Orientation to PCB |
Parallel
|
| AWG | 12-30 |
| Color | blue, green |
| Packaging | Reel, Standard |
