Technical data
MorelessPitch (mm) | 2,54 |
Mating pin size (range) |
ø 0,70-0,90 ☐ 0,64 |
Pincount | 6, 8, 10, 16 ... 72 |
Gender | Female |
Polarising | no |
Locking | No |
Material contact | Copper alloy |
Plating contact | Sn |
Material insulator | High temp. thermoplast UL94V-0 |
Rated current IEC | 3,0 A |
Rated voltage | 150 V RMS / V DC |
Withstand voltage | 500 V RMS / V DC |
Operating temperature | -55°C to +105°C |
Max. processing temper. | 260°C for 10 seconds |
Board termination | Through hole |
Orientation to PCB | Vertical |
No of rows | 2 |
Clip style | 6 finger clip |
Plating clip | Au |
Row distance (mm) | 2,54 |
Material clip | Berylium Copper |
Contact style | Turned |
Socket layout | DIL strip (Dual-in-line) |
Packaging | Standard |
