Technical data
Moreless| Pitch (mm) | 2,54 |
| Mating pin size (range) |
ø 0,70-0,90 ☐ 0,64 |
| Pincount | 1, 2, 3, 4 ... 50 |
| Gender | Female |
| Polarising | no |
| Locking | No |
| Material contact | Copper alloy |
| Plating contact | Sn |
| Material insulator | High temp. thermoplast UL94V-0 |
| Rated current IEC | 3,0 A |
| Rated voltage | 150 V RMS / V DC |
| Withstand voltage | 500 V RMS / V DC |
| Operating temperature | -55°C to +125°C |
| Max. processing temper. | 260°C for 10 seconds |
| Board termination |
Through hole
|
| Orientation to PCB |
Vertical
|
| No of rows | 1 |
| Contact type |
Standard 7
|
| Plating clip | Au, Au 0,75 µ |
| Material clip | Berylium Copper |
| Contact style | Turned |
| Socket layout |
SIL strip (Single-in-line)
|
| Packaging | Standard |
