Technical data
Moreless| Pitch (mm) | 2,54 |
| Pincount | 2, 3, 4, 5 ... 40 |
| Gender | Male |
| Mating contact size | ø 0,64 |
| Polarising | no |
| Locking | No |
| Material contact | Copper alloy |
| Plating contact | Au, Selective Au (min 5 mm on mating side), Sn |
| Material insulator | Thermoplast UL94V-0 |
| Rated current IEC | 3,0 A |
| Rated voltage | 250 V RMS / V DC |
| Withstand voltage | 500 V RMS for 1 Minute |
| Operating temperature | -40°C to +105°C |
| Max. processing temper. | 260°C for 10 seconds |
| Board termination |
SMD Gull Wing
|
| Orientation to PCB |
Parallel
|
| No of rows | 1 |
| Cap | With cap, Without cap |
| Positioning peg | With positioning peg, Without positioning peg |
| Packaging | Reel, Tube |
| A | 10,12, 10,37, 12,91, 13,16 ... 17,99 |
Drawing / Dimensions
Moreless
| A | B | C |
|---|---|---|
| 10,12 | 3,05 | 4,57 |
| 12,91 | 5,84 | 4,57 |
| 15,20 | 8,13 | 4,57 |
| 17,74 | 10,67 | 4,57 |
| 10,37 | 3,05 | 4,82 |
| 13,16 | 5,84 | 4,82 |
| 15,45 | 8,13 | 4,82 |
| 17,99 | 10,67 | 4,82 |
