Technical data
Moreless| Pitch (mm) | 2,54 |
| Pincount | 6, 8, 10, 14 ... 64 |
| Gender | Male |
| Polarising | yes |
| Locking | Positive lock |
| Material contact | Copper alloy |
| Plating contact | Au, Selective Au, Sn |
| Material insulator | Thermoplast UL94V-0 |
| Rated current IEC | 3,0 A |
| Rated voltage | 150 V RMS / V DC |
| Withstand voltage | 500 V RMS for 1 Minute |
| Operating temperature | -40°C to +105°C |
| Max. processing temper. | 260°C for 10 seconds |
| Board termination |
Through hole
|
| Orientation to PCB |
Vertical
|
| No of rows | 2 |
| Packaging | Standard |
